Comprehensive regulation

A.  Changing powder color

1)Clean the outlet hose hopper completely

2)blow into the powder hose with compressed air

3)clean the GUN

4)put the powder to be used into hopper and finish all the preparation jobs

5)turn and spray the GUN toward BOOTH momentarily before the work begains

B.How to manage

Routine maintenance of equipment prologn product life and keeps its performance uniform

1. Daily check -----INJECTOR cleaning and INSERT SLEEVE worn-down

              ^.POWDER HOSE cleaning

              ^GUN cleaning

2.weekly check  ….cleans the hopper , injector and GUN

                ..powder should not be put in the hopper just before work

               …..check the ground line between CONTROL UNIT ,  BOOTH and CONVERYOR

              ^.After checking air dehydrator , any water in it should be removed , the air ,but for checking the presence of moisture in it

C. Checking for shutdown lasting 2-3 days

1)Turn off the power switch

2)Clean the CONTROL UNIT

3)Remove the imput air and put it away

4)check above -1 .Daily check

5)Remove powder from HOPPER

Technical Data

Power range                                   220v

Frequency                                     50/60HZ

Temperature range in use                      -10 ℃+50 ℃

Powder Gun

Gun weight:    ^^^                    500G

Rated output voltage ^…                      24VDC

Input voltage     ^^…                       - 200kv

Maximum output current  ^…                   180Ua(max)

Maximum output voltage^^                   0-100KV (  adjustable)

Maximum powder injection :^…                    600g/min

Polarity ^^^                                negative (-)

Pneumatic technical spec

Maximum input-air pressure ^^..                 8kg/cm

Optimum input-air pressure^..                        6kg/cm

Minimum input-air pressure   ^                      4kg/cm

Maximum water vapor content or compressed air …..      1.4g/N m3

Maximum oil vapor content of compressed air   ^..     0.1ppm

Maximum cimpressed-air consumption^…            13.2 m3/h
