Optistar Control Unit of Powder coating Gun

Payment Terms: T/T,
Place of Origin: Zhejiang, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: colo-Optistar-T-C
Production Capacity: 200Piece/Pieces Per Month
Delivery Date: 15 days
type: Coating Spray Gun
coating: powder coating
Material / Metal: Steel,all metallic surface
Power(W): 50w
After-sales Service Provided: Overseas service center ava...
Means of Transport: Ocean,
Packing: wood box or carton box
Brand Name: colo
weight: 9.5KGS
Dimension(L*W*H): 33CM*40CM*45CM
Voltage: 220v/110v
Certification: CE/ISO
Warranty: 1 YEAR

this control unit is interchangeable with original optiselect gun. The cup is self-fluidizingand is easy to clean, making color changesfast and easy.

Specifications
1,Optistar Control Unit of Powder coating Gun
2,this control unit is interchangeable with original optiselect gun
Optistar Control Unit of Powder coating Gun
    Optistar Control Unit of Powder coating Gun
Typical characteristics
0-100 Digital Adjustable KV
Fully Adjustable Amperage
Interchangeable with the original equipment OPTIFLEX
Fully Adjustable Air for Pump on Pressure, Dosage and Nozzle Rinsing Air.
Comes with Full Array of Nozzle Assortment.
Field Tested and Proven to operate in the toughest environments.
Comes with different array of delivery systems:

Because this system is specially balanced for the maximum spray capability with
the Smoothest Finish Possible.

Technical data:
Electrical data
Mains input voltage: 220V/110V
Operating frequency: 50Hz /60Hz
Powder: 50W
Output voltage (to the gun): 0-100KV ( adjustable)
Maximum output current (to the gun): 180UA(max)
Protection type: IP54
Approvals: CE Certification
Pneumatical data
Input pressure: Min. 6 bar(87PSI)/max. 10 bar(145PSI)
Recommended input pressure: 7 bar(101.5PSI)
Max. Water vapor content of the compressed
Air 1.3 G/m 3;
Max. Oil vapor content of the compressed air 0.1 mg/m3;
Dimensions
Carton size: 33CM*40CM*45CM G. W: 9.5kg.
Optistar Control Unit of Powder coating Gun
Optistar Control Unit of Powder coating Gun
Optistar Control Unit of Powder coating Gun



Theprocess of the coating is like this :the powder is fluidized in thepowder hopper. The injectors transport the powder through the hoses tothe guns . The guns spray a powder/air mixture onto the workpieces.
Powdercoating is a type of coating that is applied as a free-flowing, drypowder. The main difference between a conventional liquid paint and apowder coating is that the powder coating does not require a solventto keep the binder and filler parts in a liquid suspension form. Thecoating is typically applied electrostatically and is then cured underheat to allow it to flow and form a "skin". The powder may be a thermoplastic or a thermoset polymer.It is usually used to create a hard finish that is tougher thanconventional paint. Powder coating is mainly used for coating of metals, such as "whiteware," aluminium extrusions, and automobile and bicycle parts. Newer technologies allow other materials, such as MDF (medium-density fibreboard), to be powder coated using different methods.
The powder coating process involves three basic steps:
  1. Part preparation or the pre-treatment
  2. The powder application
  3. Curing
COLOPowder Coating Systems is a top supplier of powder coating systems andpowder coating equipment including automated equipment, spray booths andspare parts for itw gema , wagner , nodrson , kci famous brand inchina.
